Belt Scales



For all types of material and
conveyors - S-E-G belt scales

THE INDUSTRIAL WEIGHING SPECIALIST

BELT SCALES FROM S-E-G

When material can be conveyed on a belt it can be weighed - rock, wood chips, oranges, fish or whatever. Belt scales from S-E-G are used in more than 30 countries. Rugged, dependable scales for heavy duty use. Over 10,000 delivered scales have taught us everything there is to know in conveyor weight.

Reliable
Robust design with few moving parts for minimum maintenance, long life and good economy.

Accurate
From simple flows to precision weighing. Availble in all UE certification classes.

Easy to use
Clear information in plain text, alarm- and control signals and intelligent automatic calibration.

Modular
standardized modules for short delivery time, simple installation and fafe spare part availability.

Belt weighing Unit

  • Simple installation with minimum conveyor intervention.
  • Adjustable to existing belt profiles.
  • Patented design eliminates side- and friction forces.
  • Built in overload protection.
  • Heavy duty load cell in protected location.
  • Standard units for 400 - 2 500 mm belt width.
  • With precision idled set or used with existing idler set.

Control Console

  • From simple flow to advanced system with regulartor, load out and control.
  • Flush prof user panel with large keys.
  • Clear alfanumeric text display.
  • Build in functions for alarm, control and calibration.
  • Interfaces with regulators, printer and computers.
  • Stainess steel enclosure for wall or panel mount.
belt scales

Tachometer

  • Measures the speed of the belt.
  • Can measure directly on the belt or on conveyor idler.

Connection Box

  • Connects 1 - 4 weighing units and tachometer.
  • Stainless steel enclosure.

More

pdf Belt weighing unit data sheet
